FEELWORLD T7S Pro 7-inch 2000nit High Brightness Filed Camera Video Monitor 3G SDI 4K 60Hz HDMI-compatible 1920 x 1200 IPS Screen(Black)

Display Spec.1. Model: T7S PRO2. Screen Size: 7 inch IPS3. Resolution: 1920x1200 pixels4. Pixel Pitch: 0.07875(W) x 0.07875 (H) (mm)5. Color Depth: 8bit6. Aspect Ratio: 16:107. Brightness: 2000cd/m28. Contrast Ratio: 1200:19. Backlight: LED10. Viewing Angle: 80 degree / 80 degree (L/R) / 80 degree /80 degree (U/D) Input1. 1 x SDI: 3G-SDI2. 1 x HDMI-compatible: HDMI-compatible 2.03. 1 x USB: Mini USB (LUT file import and Firmware update) Output4. 1 x SDI: 3G-SDI5. 1 x HDMI-compatible: HDMI-compatible 2.0 AudioAudio: 3.5mm Stereo Headphone 3G-SDI Input and Output Support Format1. 720p (60/59.94/50/30/29.97/25/24/23.98)2. 1080i (60/59.94/50)3. 1080p (60/59.94/50/30/29.97/25/24/23.98) HDMI-compatible Input and Output Support Format1. 720p (60/59.94/50/30/29.97/25/24/23.98)2. 1080i (60/59.94/50)3. 1080p (60/59.94/50/30/29.97/25/24/24sF/23.98/ 23.98sF)4. 4K 3840 x 2160p (60/50/30/29.97/25/24/23.98)5. 4K 4096 x 2160p(60/50/30/29.97/25/24/23.98) General1. Power Connector: DC IN2. Input Voltage: DC7～24V3. Power Consumption: Less than or equal to 18W4. Working Temperature: -20 degree C~55 degree C5. Storage Temperature: -30 degree C~65 degree C6. Install Way: 1/4-20 Thread Point (bottom)7. Unit Size: 182.8x122.8x24 (mm)8. Unit Weight: 370g Advanced Features1. Support 3D LUT Log to Rec.709, user 3D LUT Upload (up to 32)2. Waveform (RGB, YUV, Y)3. HDR4. Vector5. Histogram (RGB,Y )6. Embedded Audio7. Focus Assist(Red, Green, Blue three focus colors optional; 1~10 focus level adjustable)8. False Colors (Normal, ARRI)9. Over Exposure (10IRE～100IRE adjustable)10. Check Field (Red, Green, Blue, Mono)11. Scan Mode (Under Scan, Over Scan)12. Anamorphic Mode (1.33x, 1.6x, 2.0x, 2.0x mag, User. Under User, you can custom adjust nx 1.20x~2.00x)13. Image Flip (H Flip, V Flip, H_V Flip )14. Image Freeze15. Center Marker16. Safety Frames (80%, 85%, 90%, 93%, 96%, 2.35:1, 9:16)17. Aspect Ratio (Auto, 16:9, 16:10, 4:3, 5:4, 1.85:1, 2.35:1, Full Screen)18. Ratio Marker(4:3, 13:9, 14:9, 15:9, 16:9, 1.85:1, 2.35:1, 9:16)19. Marker Color (Red, Green, Blue, Black, White, Gray)20. Grid (2x2, 3x3, 4x4, 5x5, 6x6, 7x7, 8x8, 9x9, Custom. When selecting Custom, you can custom the rows and columns from2~9)21. Zoom Mode (2X, 4X, 9X, 16X, User. Under User, you can adjust 100%~200%)22. Pixel to Pixel23. SDI Time Code(LTC, VITC)24. Display Range( Auto, Limit, Full)25. EDID Settings(2.0,1.4)26. User Switch (1~4)27. OSD Time(Off, 15Sec, 30Sec, 45Sec)28. OSD Transparency (Off, 25%, 50%, 75%)29. The background color of screen when no signal (Red, Green, Blue, Black, White, Gray)30. Power Settings (Auto, Manual)31. Color Temp.(5600K, 6500K, 9300K, User. Under User, the red, green, and blue values of the image can be adjusted 0~255)Packaging List:1. Monitor x 12. Micro HDMI-compatible Cable x 13. HDMI-compatible Cable x 14. Mini Hot shoe mount + Hex Wrench x 15. USB to Mini USB Cable x 16. Sun Shade + Frame x 17. Cable Management Tie x 18. Manual x 1
